THE DIRECTOR D4600 16 CHANNEL/100W
Brand:
AUDIO CONTROL
|
| Article code | D4600 |
| EAN |
Information
FEATURES
- Network DSP Amplifier With Volume Control
- 16 Channels x 100 Watts at 8 Ohms (All Channels Driven)
- 16 Channels x 200 Watts at 4 Ohms (All Channels Driven)
- Bridgeable to 400 Watts of Bridged Power
- Digital Signal Processing (DSP) Performance
- Built-In Speaker Optimization Profiles
- Ethernet Port for Status Monitoring, Source Switching and 12 Volt Trigger Control
- Network Programmable Graphic & Parametric Equalization with User Memories
- Assignable Names for All Zones & Amplifier
- Digital Signal Sense
- Programmable Electronic Crossover for Local Subwoofer Applications; Subsonic Filter
- AudioControl LightDrive Anti-Clipping Speaker Protection
- Local Inputs with Pass Thru / Loop Outputs
- Dual Analog Bus Inputs
- Compact 2U Rack Space (Includes Rack Mount Brackets)
- Home and Commercial Installations
SPECIFICATIONS
INPUTS
- Inputs: 8 Stereo Local Inputs, 2 Stereo Bus Inputs
- Input Sensitivity: 1 Vrms for full output, level at maximum
- Input Gain: 30 dB
OUTPUTS
- Amplifier Channels: 16
- Power Output (8Ω): 100W per channel
- Power Output (4Ω): 200W per channel
- Power Output (8Ω Bridged Mono): 400W
- Minimum Speaker Load: 4Ω
- Preamp Audio Outputs: 8 Stereo Local Loop Outputs, 1 Stereo Bus Loop Output
PERFORMANCE
- Signal to Noise: >95 dB, A-wtd, ref full output
- Crosstalk: > 80 dB @ 1 kHz
- Damping Factor: >300
CONTROL
- Remote Power Trigger: +12 VDC or Dry Contact Closure
- Network Connection/Protocol: 10BaseT Ethernet TCP/IP
- Communication Protocol: HTTP or Telnet
WEIGHTS & DIMENSIONS
- Dimensions: 17” W x 15.5” D x 3.5” H (2U)
- Weight: 19.2 lbs (8.7 kg)
- IN THE BOX: The Director Model D4600, Speaker Connectors, Remote Connector, Power Cord, Manual, Warranty
