SPECS

SKU
PRO-CF69.4NR
Nominal Diameter
6x9" / 152 x 228mm
Nominal Impedance
4 OR 2 OHMS
RMS Power Handling
300 WATTS
Maximum Power Handling
600 WATTS
Sensitivity (1w/1m)
95 dB
Frequency Response
63Hz - 12KHz
Recommended Hi Pass Crossover
80 Hz

SPECS

Voice Coil Diameter
2" / 50 mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Basket Material
Steel
Magnet Weight
10.5Oz / 0.3Kg

THIELE & SMALL PARAMETERS

Vas
12.75L / 0.45 ft3
Xmax
2.5 mm
Fs
83 Hz
Qms
12.16
Qes
0.69
Qts
0.65
Re
3.4 OHM

MEASUREMENTS

Overall Diameter
6.48" x 9.29" / 164.5 x 236 mm
Front Mount Baffle Cutout
5.94" x 8.58" / 151 x 218 mm
Mounting Depth
3.25" / 82.5 mm
Overall Depth
3.44" / 87.5 mm
Product Weight
4.5 lbs
Product Dimensions
10.75 x 8 x 4.5
M/C Weight
18.5 lbs
M/C Dimensions
16.5 x 11.25 x 10.5
M/C QTY
4
Sold In
Piece
