SPECS

SKU
IXS10.4D
Nominal Diameter
10" / 254mm
Nominal Impedance
4+4 ohms
RMS Power Handling
600w
Maximum Power Handling
1200w
Sensitivity (1w/1m)
84 dB
Frequency Response
20 - 800 Hz
Recommended Lo Pass Crossover
90 Hz

MOTOR

Voice Coil Diameter
2.5" / 63.5mm
Voice Coil Former Material
Aluminum
Winding Material
Copper
Cone Material
Paper
Dust Cap Material
Fiberglass
Surround Material
Stitched rubber
Basket Material
Aluminum
Basket Color/Finish
Corrugated Black
Magnet Material
Ferrite
Magnet Weight
62 Oz
Displacement Volume
0.9L / 0.032ft3

THIELE & SMALL PARAMETERS

Equivalent Volume Vas
18.67L / 0.66ft3
Free Air Resonance Fs
38 Hz
Mechanical Factor Qms
4.418
Electrical Factor Qes
1.001
Total Factor Qts
0.816
Moving Mass Mms
149.83 g
Compliance Cms
0.12 mm/N
Bl Factor BI
8.43
Voice Coil Inductance Le
1.569 mH
Diaphragm Area Sd
333.29 cm2
DC Resistance Re
4+4 ohms
Efficiency Bandwidth Product EBP
37.9
