| SPECIFICATIONS |
|
| GENERAL: |
|
| Operating Voltage: |
10.5 -16 Volts |
| Low Voltage Warning Alert: |
YES (< 11V) |
| Waterproof Rating: |
IPX6 |
| UV/Salt Protection: |
YES |
| Buttons: |
Rubber + RGB Backlit (synced with LCM) |
| Screen Panel: |
Gorilla Glass with OCA Full Bonding |
| DISPLAY: |
|
| Type: |
Liquid Cristal Module |
| Backlight: |
7 Colors Selectable (Auto / White / Red / Blue / Green / Purple / Cyan / Yellow |
| AUDIO: |
|
| Power Output RMS: |
4 x 15W @ 4ohm / 4 x 25W @ 2ohm |
| Max: |
4 x 50W @ 2ohm |
| Min Load: |
2 ohm Stable per Channel |
| Frequency Response: |
20Hz to 20Khz |
| RCA Pre-Out Voltage: |
4 Volts |
| Output Impedance: |
500 ohm |
| Equalizer: |
2 Bands (Bass 80Hz, Treble 12Khz) |
| Presets: |
YES (S-Bass / Vocal /Powerful / clarity) |
| Subwoofer Control: |
Level (-10 to +10) |
| Audio Zones: |
2 Zones (Stereo + Subwoofer each) |
| Independent Zone Control: |
YES (Level/Tone) |
| Audio Input: |
L+R RCA (Aux Input) |
| TUNER: |
|
| FM Frequency Range: |
87.5 -107.9 MHz |
| AM Frequency Range: |
530 -1710 KHz |
| Weather Band: |
162.40 -162.55 MHz |
| NOAA Weather Band: |
YES Compatible |
| Tuner Presets: |
18 FM / 12 AM / 6 WB |
| Radio Data System: |
YES (AF / TA / NEWS) Selectable |
| CONNECTIVITY: |
|
| Bluetooth Version: |
5.0 + EDR |
| Audio Streaming: |
A2DP |
| USB Compatibility: |
v2.0 |
| USB Capacity: |
64 Gb Max |
| USB Charge Capacity: |
2.1Amp |
| Audio Files Compatibility: |
MP3, WMA |
| Remote Control: |
Wired 3.5mm Jack Input (Compatible with MXRC) |
