Engineered to Fit. Built to Perform.

The P1 PUNCH speakers are simple, all-in-one upgrades for standard factory systems. The P1 are perfect for Basic OEM systems with single-speaker locations in doors or rear decks. Factory single cone drivers don’t have tweeters and replacing them with a 3-way coaxial will deliver a big leap in sound clarity and “punch”.

Kit Includes:
• (2) 6.0" Speakers
• Installation Hardware

FEATURES AT A GLANCE

• Updated mounting flanges for direct fitment in new vehicles
• 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
• 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
• 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
• Santoprene™ half-roll surround for low distortion and unmatched fatigue resistance
• Co-molded surround and cone body chemically bonded for high durability
• Fatigue and tear resistant linear Nomex® spider
• Ultra-flexible braded tinsel leads securely stitched to spider
• 15% glass-fiber reinforced PA66 injected molded composite basket
• Vented Kapton® voice coil former for excellent heat dissipation
• Overhung voice coil ensures consistent magnetic flux for less speaker distortion
• High strength Y35 ferrite motor structure (5mm larger over previous generation)
• Removable motor cover for fitment in tight applications
• Co-molded basket terminals for secure connectivity
• ICC+ internal concealed 6dB/octave crossover network
• Includes mounting hardware
• Includes cut-out template
• Grilles sold separately
• Sold in pairs (2 each)
• 2-Year Warranty

CTA-2031 Compliant

Speaker Type

Coaxial

Midrange Size
(Nominal Diameter)

6.0"

Tweeter Size
(Nominal Diameter)

3/4” (19 mm)
Inverted Dome

Piezo Size
(Nominal Diameter)

3/8” (9 mm)
Co-Witnessed Convex

Nominal Impedance
(Ohms)

4Ω

Frequency Response
(Hz)

53Hz - 25kHz

Voice Coil Diameter
(in/mm)

1" (25.4 mm)

Power Handling
(Watts RMS)

75 Watts RMS
150 Watts Peak

Crossover

Tweeter High-Pass: 9kHz @ 6 dB/Octave

Fs (Hz)

70 Hz

Sensitivity
(dB @ 1W/1M)

88 dB
