SPECS

SKU
PRO-TWN1
Nominal Diameter
3"
Nominal Impedance
4 OHMS
AES Power Handling
60 Watts
Program Power Handling
120 Watts
Peak Power Handling
240 Watts
Sensitivity (1w/1m)
104 dB
Frequency Response
3KHz - 20KHz
Recommended Hi Pass Crossover
3 KHz

MOTOR

Voice Coil Diameter
1" / 25.4 mm
Voice Coil Former Material
NSV
Winding Material
Pure Aluminum Round Wire
Diaphragm Material
Titanium
Magnet Material
Neodymium
Magnet Size
0.96" x 0.27"
Body Material
Aluminum
Bullet Material
CNC Aluminum

MEASUREMENTS

Overall Diameter
2.93" /74.4mm
Overall Depth
1.87" /47.5mm
Front Mount Baffle Cutout
2.32" /59mm
Mounting Depth
1.61" /41mm
Product Weight
1 lbs
Product Dimensions
3.75 x 3.175 x 2.25
M/C Weight
35.5 lbs
M/C Dimensions
16.5 x 8.25 x 8.25
M/C QTY
30
Sold In
Piece
