RF POWER T1 10" 600W SUB DVC
Brand:
ROCKFORD FOSGATE
|
| Article code | T1D410 |
| EAN | 780687328924 |
Information
Power 10" T1 4-Ohm or 2-Ohm DVC Subwoofer T1D410/T1D210
Innovative technologies allow the T1 subwoofer to perform like a larger woofer over the previous model. The T1 10” features dual 4-Ohm/2-OHM voice coils, 600 Watts RMS power handling, and includes a grille with integral trim ring.
Power Handling (Watts RMS)
600 Watts RMS
1200 Watts Max
1200 Watts Max
Nominal Impedance
Dual 4-Ohm
Magnet Weight (oz)
100 oz. (2.84 kg)
Size
10"
Voice Coil Diameter
3" (75.4mm)
SPL (dB @ 1w/1m)
83
Fs (Hz)
36
Woofer Displacement
0.078 cu. ft. (2.2 Liters)
Qes
0.73
Cutout Diameter
9.0625 in. (230 mm)
Qts
0.65
Speaker Connector
Compression Terminal
Mounting Depth
6.375 in. (161.9 mm)
Speaker Connector
Compression Terminal
Qms
5.70
Shipping Weight
25.7 Lbs. (11.65 Kg.)
Vas (Liters)
15.7
Xmax (mm)
16
Re (Ohms)
6.50
Le (mH)
2.5
CEA-2031 Compliant
Subwoofer Type
Standard
Voice Coil Type
Dual Voice Coil
Sealed Box Volume (Vb)
0.75 cu. ft. (21.2 Liters)
Vented Box Volume (Vb)
1.5 cu. ft. (42.4 Liters)
