SPECS

SKU
TX1
Nominal Diameter
2"
Nominal Impedance
4 OHMS
AES Power Handling
25W
Program Power Handling
50W
Peak Power Handling
200W
Sensitivity (1w/1m)
88 dB
Frequency Response
2K-20KHz
Recommended Hi Pass Crossover
3KHz
Pair
Yes

MOTOR

Voice Coil Diameter
0.5"
Voice Coil Former Material
KSV
Diaphragm Material
PEI Dome
Magnet Material
Ferrite
Body Material
Plastic

MEASUREMENTS

Overall Diameter
2.4" / 60.96mm
Overall Height
1.24" / 31.49mm
Front Mount Baffle Cutout
2" / 50.8mm
Mounting Depth
0.71" / 18.03mm
