NVY-IPX7.4

NVY 4-Channel Full-Range IPX7 Submersible Marine and Powersports Amplifier 120 x 4 @ 4-Ohm Watts RMS

• General Specifications
• Total Watts (Peak): 1440W
• RMS Power @ 4 ohm: 4 x 120W
• RMS Power @ 2 ohm: 4 x 200W
• RMS Power @ 4 ohm Bridge: 2 x 350W

• Audio Specifications
• Frequency Response: 20Hz-20KHz
• Signal to Noise Ratio: 1W@4Ω ＞90dB
• Efficiency @ 4ohm: 94%
• Input Impedance:＞20KΩ
• Channel Separation: ＞-70dB
• Total Harmonic Distortion: (THD)＜0.1%
• Low Level Input Range: 270mV-5.6V
• Selectable X-Over: HPF/FULL/LPF
• X-Over Filter Range: 50Hz-4KHz

• Features
• Amplifier Class: Digital (D)
• Amplifier Type: Full Range Digital Marine Amplifier
• Number of Channels: 4
• Minimum Impedance: 2 ohms/Ch (4 ohm Bridge)
• Led Indicator Protection (Red) / Power (Blue)
• Power Input Size: 8Ga
• Fuse: 2 x 30A
• Thermal Protection: Yes
• Over-Load Protection: Yes
• Short Circuit Output Protection: Yes
• Voltage Input Protection: Yes (9.5-16V)
• Body Color / Finish Black / Anodizing

• Extra Features
• 2Ch/4Ch Input Selector: Yes
• Waterproof Rating: IPX7
• UV / Salt Fog Protection: Yes
• Power Direct Harness Design: Yes
• Surface Mount Component Technology: Yes
• Marine Grade Fuse Holder: Yes

• Measurement
• Overall Length: 10" / 253mm
• Overall Width: 4.5" / 116mm
• Overall Height: 1.9" / 48.5mm
• Heatsink Length: 8.5" / 216mm
• Gross Single Unit Weight: 1.8kg
